Specifications

Product
Canfield Balance Bike
Model Year
2023
Riding Type
Enduro / All-Mountain
Freeride / Bike Park
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
Wheel Size
27.5" (650b)
Frame Material
Aluminum
Frame Material Details
7005 aluminum, CNC links, molded chainstay protection
Rear Travel
169mm
Rear Shock
230mm x 65mm
Options: Cane Creek Kitsuma Air, Cane Creek Kitsuma Coil, DVO Topaz Air, DVO Jade X Coil, RockShox Super Deluxe RCT Air, MRP Hazzard Coil, Öhlins TTX2 Air, EXT Storia V3-S
Fork
Options: Cane Creek Helm MKII Air, DVO Onyx, MRP Ribbon Air, RockShox Lyrik Ultimate
Fork Travel
170mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
44mm upper, 56mm lower
Handlebar
Canfield Carbon, 800mm width, 35mm clamp diameter
Stem
Canfield, 40mm length, 35mm bar clamp
Grips
Lizard Skin Charger Evo, lock-on, with Canfield lock-ring
Brakes
Options: TRP Slate T4, TRP Slate EVO, Magura MT5, Magura MT5 HC, Magura MT7 HC3
Brake Levers
Options: TRP Slate T4, TRP Slate EVO, Magura MT5, Magura MT5 HC, Magura MT7 HC3
Drivetrain
1x
Shifters
Options: TRP TR12, SRAM X01 Eagle
Front Derailleur
None
Rear Derailleur
Options: TRP TR12, SRAM X01 Eagle
ISCG Tabs
ISCG05
Chainguide
None
Cranks
Canfield, 155mm/165mm/170mm length options
Chainrings
absoluteBLACK, round, 32 tooth
Bottom Bracket
Canfield GXP, 73mm English/BSA threaded
Pedals
None
Chain
Options: TRP TR12, SRAM X01 Eagle
Cassette
Options: e*thirteen Helix R, 12-speed, 9-50 tooth (with TRP TR12 drivetrain); SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth (with SRAM X01 Eagle drivetrain)
Rims
Options: e*thirteen LG1 Plus Enduro Alloy, Atomik AM32 Carbon, Atomik FM30 US Fusion Fiber
Hubs
110x15mm Boost front, 148x12mm Boost rear
Options: e*thirteen LG1 Plus Enduro wheelset, Industry Nine Hydra (with Atomik Carbon rims)
Spokes

Tires
Front: Maxxis Minion DHF, 27.5" x 2.5"
Rear: Maxxis Dissector, 27.5" x 2.4"
Saddle
SDG Bel-Air, custom Canfield version
Seatpost
SDG Tellis dropper
Drop: 150mm (SM/MD), 170mm (LG/XL)
Seatpost Diameter
30.9mm
Seatpost Clamp
Single bolt, 35mm
Rear Dropout / Hub Dimensions
148x12mm Boost
Max. Tire Size
27.5" x 2.6"
Bottle Cage Mounts
One under down tube
Colors
Goat's Blood, Stealth
Warranty
2 years frame
Weight

Miscellaneous
• CBF (Canfield Balance Formula) rear suspension design
• Internal cable routing
• Compatible with mixed ("Mullet") wheels: 29" front, 27.5" rear
• Convertible to 157mm rear travel with 60mm-stroke shock
• Includes Trucker Co. Cream II tubeless sealant
Price
$5,799.99
