Specifications

Product

Airdrop Filter Launch LTD Edition Bike

Model Year

2022

Riding Type

Trail

Enduro / All-Mountain

Rider

Unisex

Sizes and Geometry

Size	SM	MD	LG	XL

Head Tube Angle	65°	65°	65°	65°
Head Tube Length	115mm	120mm	125mm	130mm
Seat Tube Angle	74.5°	74.5°	74.5°	74.5°
Seat Tube Length	400mm	425mm	450mm	480mm
Bottom Bracket Height	22mm drop	22mm drop	22mm drop	22mm drop
Chainstay Length	430mm	430mm	430mm	430mm
Wheelbase	1167.2mm	1199.3mm	1221.4mm	1248.5mm

Reach	425mm	455mm	475mm	500mm
Stack	605.3mm	609.7mm	614.5mm	618.8mm
Additional Info	Above seat tube angle values are for actual angle; effective values at example saddle heights: 78.7° (600mm), 78.1° (700mm), 77.7° (800mm)

Wheel Size

27.5" (650b)

Frame Material

Aluminum

Frame Material Details

Custom-butted 6061-T6 alloy

Rear Travel

135mm

Rear Shock

Cane Creek DB Coil IL, trunnion mount, 185mm x 55mm

Fork

Cane Creek Helm MkII Air, 37mm offset

Fork Travel

150mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Cane Creek 40, ZS44 upper, ZS56 lower

Handlebar

Burgtec Ride Wide, 800mm width, 30mm rise, 35mm clamp diameter

Stem

Burgtec Mk3 Enduro, 35mm length, 35mm bar clamp

Grips

Burgtec Bartender Pro, lock-on

Brakes

SRAM G2 RSC, 4-piston, SRAM CenterLine rotors (200mm front, 180mm rear)

Brake Levers

SRAM G2 RSC

Drivetrain

Shifters

SRAM GX Eagle, 12-speed

Front Derailleur

None

Rear Derailleur

SRAM GX Eagle, 12-speed

ISCG Tabs

ISCG05

Chainguide

None

Cranks

SRAM GX 7K Eagle DUB, 170mm length

Chainrings

SRAM GX 7K Eagle, 32 tooth, direct mount

Bottom Bracket

SRAM DUB, 73mm English/BSA threaded

Pedals

None

Chain

SRAM GX Eagle, 12-speed

Cassette

SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth

Rims

WTB Proterra Tough i30 wheelset, 30mm inner width

Hubs

WTB Proterra Tough i30 wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver

Spokes

WTB Proterra Tough i30 wheelset

Tires

Michelin Wild AM, 27.5" x 2.4"

Saddle

WTB Volt Race Custom

Seatpost

OneUp V2 dropper, 1x remote lever

Seatpost Diameter

30.9mm

Seatpost Clamp

Airdrop CNC, single bolt, 35mm

Rear Dropout / Hub Dimensions

148x12mm Boost

Max. Tire Size

27.5" x 2.6"

Bottle Cage Mounts

One inside front triangle

Colors

Raw with Gloss powdercoat, Grey with Matte powdercoat

Warranty

2 years frame, with 5 year crash replacement program

Weight

31 lb 4.9 oz (14,200 g)

Miscellaneous

• Four-Bar Horst Link rear suspension design
• External cable routing with internal dropper post routing
• Above weight given for size LG
• Includes WTB TCS rim tape and tubeless valves, with Muc-Off tubeless tire sealant
• UK price: 3499 GBP

Price

More Info

Alloy, 135mm-travel, 27.5-inch wheels - The New Airdrop Filter (press release)
