Specifications

Product
Transition Patrol Alloy GX TRP Bike
Model Year
2022
Riding Type
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
SM (High, Low)
MD (High, Low)
LG (High, Low)
XL (High, Low)
Wheel Size
27.5" (650b)
29"
Other: Mullet
Frame Material
Aluminum
Frame Material Details
6061 heat-treated alloy; molded chainstay, seatstay, and down tube protection
Rear Travel
160mm
Rear Shock
RockShox Super Deluxe Ultimate Air, trunnion mount, 205mm x 60mm
Fork
RockShox ZEB Ultimate, 44mm offset
Fork Travel
160mm
Head Tube Diameter
Straight, 56mm
Headset
FSA No.55R/57, ZS56 upper/lower
Handlebar
ANVL Mandrel Alloy, 800mm width, 35mm clamp diameter
Rise: 20mm (SM), 30mm (MD-XL)
Stem
ANVL Swage, 40mm length, 35mm bar clamp
Grips
ODI Elite Flow
Brakes
TRP DH-R Evo, 4-piston, TRP R1 203mm rotors (2.3mm thick)
Brake Levers
TRP DH-R Evo
Drivetrain
1x
Shifters
SRAM GX Eagle, 12-speed
Front Derailleur
None
Rear Derailleur
SRAM GX Eagle, 12-speed
ISCG Tabs
ISCG05
Chainguide
OneUp upper slider with bashguard
Cranks
SRAM GX Eagle Alloy DUB, 165mm length
Chainrings
SRAM GX Eagle, 32 tooth
Bottom Bracket
SRAM DUB, 73mm English/BSA threaded
Pedals
None
Chain
SRAM GX Eagle, 12-speed
Cassette
SRAM GX Eagle XG-1275, 12-speed, 10-52 tooth
Rims
Stan's NoTubes Flow S1
Hubs
Stan's NoTubes Neo Durasync, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Spokes
Sapim Race, double-butted
Tires
Front: Schwalbe Magic Mary, Super Trail casing, Addix Soft compound, 29" x 2.4"
Rear: Schwalbe Big Betty, Super Trail casing, Addix Soft compound, 27.5" x 2.4"
Saddle
ANVL Forge Cromo
Seatpost
OneUp V2 dropper
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 34.9mm
Rear Dropout / Hub Dimensions
148x12mm Boost
Max. Tire Size
27.5" x 2.6"
Bottle Cage Mounts
One inside front triangle, plus accessory mounts under top tube
Colors
Raw, Blueberry
Warranty
Lifetime frame
Weight

Miscellaneous
• GiddyUp four-bar rear suspension design
• Mixed ("Mullet") wheels: 29" front, 27.5" rear
• Geometry adjustable via flip chip at lower shock mount
• Internal cable routing
• External rear brake hose routing
• SRAM UDH (Universal Derailleur Hanger)
• Includes tubeless valves and Stan's NoTubes tire sealant
• Frame weight: 10.2lbs (4.63kg), size MD, with FOX FLOAT X2 shock
Price
$5,299.00
More Info

transitionbikes.com
