Specifications

Product

Whyte T-140 RS 29er Bike

Model Year

2023

Riding Type

Trail

Rider

Unisex

Sizes and Geometry

SM (High, Low)

MD (High, Low)

LG (High, Low)

XL (High, Low)

Size	SM (High, Low)	MD (High, Low)	LG (High, Low)	XL (High, Low)
Top Tube Length	575.0mm	603.9mm	636.6mm	667.7mm
Head Tube Angle	65.3°, 64.7°	65.3°, 64.7°	65.3°, 64.7°	65.3°, 64.7°
Head Tube Length	107mm	120mm	135mm	148mm
Seat Tube Angle	76.4°	76.2°	76.0°	75.8°
Seat Tube Length	395mm	420mm	445mm	470mm
Bottom Bracket Height	338mm, 330mm	338mm, 330mm	338mm, 330mm	338mm, 330mm
Chainstay Length	435mm	435mm	435mm	435mm
Wheelbase	1184.7mm	1215.1mm	1249.5mm	1282.0mm
Standover	735mm	735mm	735mm	735mm
Reach	455mm	455mm	483mm	510mm
Stack	633.2mm	633.2mm	646.8mm	658.5mm
Additional Info	All specifications listed are with 140mm travel fork

Wheel Size

29"

Frame Material

Aluminum

Frame Material Details

6061 SCR aluminum alloy, molded chainstay and down tube protection

Rear Travel

135mm

Rear Shock

FOX FLOAT DPS Performance Elite, EVOL LV, 3-position compression lever, rebound adjust

Fork

FOX FLOAT 34 Performance Elite, GRIP2 damper, 44mm offset

Fork Travel

140mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

FSA No.57 Orbit ZS, sealed angular cartridge bearings

Handlebar

Whyte, 6061 alloy, 31.8mm clamp diameter
SM: 760mm width, 15mm rise
MD-XL: 780mm width, 30mm rise

Stem

Whyte Gravity, 35mm length, 31.8mm bar clamp

Grips

Whyte Enduro, lock-on

Brakes

SRAM Guide G2 R, 4-piston, 180mm rotors

Brake Levers

SRAM Guide G2 R, Matchmaker MMX clamps

Drivetrain

Shifters

SRAM GX Eagle, 12-speed, Matchmaker MMX mounting bracket

Front Derailleur

None

Rear Derailleur

SRAM GX Eagle, 12-speed

ISCG Tabs

ISCG05 2-bolt

Chainguide

None

Cranks

SRAM X1 Eagle DUB, 170mm length

Chainrings

SRAM X1 Eagle, X-SYNC 2, direct mount, 32 tooth

Bottom Bracket

SRAM DUB, 73mm English/BSA threaded

Pedals

None

Chain

SRAM Eagle, 12-speed

Cassette

SRAM NX Eagle PG-1230, 12-speed, 11-50 tooth

Rims

Race Face AR30 Offset, sleeved joint, 30mm inner width, 32 hole, tubeless ready

Hubs

Alloy, double sealed cartridge bearings, 110x15mm Boost front, 148x12mm Boost rear with 9° micro-engagement 4-pawl freehub and HG driver

Spokes

DT Swiss Champion, 2.0mm, stainless steel, with brass nipples

Tires

Front: Maxxis Minion DHF, 3C MaxxTerra compound, EXO casing, TR, 60 TPI, 29" x 2.5" WT
Rear: Maxxis Dissector, 3C MaxxTerra compound, EXO+ casing, TR, 60 TPI, 29" x 2.4" WT

Saddle

Whyte Custom, Dual Density, Triple Panel Design

Seatpost

BikeYoke Divine dropper, 160mm drop, BikeYoke Triggy MMX remote lever

Seatpost Diameter

30.9mm

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

148x12mm Boost

Max. Tire Size

Bottle Cage Mounts

One inside front triangle

Colors

Matte Diesel Light Blue/Slate

Warranty

4 years frame with registration, lifetime frame bearings

Weight

N/A

Miscellaneous

• Quad 4 Horst-Link rear suspension design
• Internal cable routing
• UK price: 4099 GBP

Price

N/A
